Home » True RMS Clamp Meter with Flexible Current Probe & ISO Certificate
True RMS Clamp Meter with Flexible Current Probe & ISO Certificate - IC790
True RMS Clamp Meter with Flexible Current Probe & ISO Certificate - IC790

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

Reed Instruments

True RMS Clamp Meter with Flexible Current Probe & ISO Certificate

SKU: IC790
(0)
$509.00 For better pricing, click here
Non-Member Pricing: This price is for non-members. Apply for membership here to access member pricing and benefits.
In stock
Ships in 7-10 days

Got questions?

Feel free to get in touch

Non-Member Pricing: This price is for non-members. Apply for membership here to access member pricing and benefits.
  • Measures AC/DC current and voltage, resistance, capacitance, frequency, duty cycle, and contact temperature
  • Comes equipped with an 18" flexible current probe that can expand AC current measurements up to 3000A
  • 6000-Count backlit LCD display and analog bargraph plus built-in non-contact voltage detector with LED indicator
  • Ergonomic design fits in your hand and can be used while wearing protective gloves and only weighs 15.8oz (447g)
  • Built-in LED flashlight, durable double molded plastic housing, and low battery and over range indicators
  • True RMS voltage and current for accurate measurements
  • Low pass filter and low impedance (LoZ) modes
  • Min/Max, display hold and relative mode
  • Diode test and continuity check functions
  • Cat. III 1000V, Cat. IV 600V safety rating
  • Operating temperature of 32 to 122°F (0 to 50°C) and a storage temperature of 14 to 140°F (-10 to 60°C)
  • Runs on 3 x AAA batteries and features an autoshut-off after 15 minutes
  • CE and ETL product certifications
  • AC/DC voltage range: 6, 60, 600, 1000V (AC), 600mV, 6, 60, 600, 1000V (DC)
  • AC/DC voltage accuracy: ±(1.0% rdg. +8 dgt.) (AC), ±(0.5% rdg. +5 dgt.) (DC)
  • AC/DC voltage resolution: 0.1mV, 0.001V, 0.01V, 0.1V, 1V
  • Includes: REED 1000A True RMS digital clamp meter (R5055), REED 3000A Flexible 18" current probe (R5065), ISO Certificate with full data and uncertainties
  • Items with calibration certificates are non-returnable and non-refundable due to the limited validity of the certification
AC/DC Current Accuracy AC/DC: ±(2% rdg. +5 dgt.)
AC/DC Current Range 60, 600, 1000A
AC/DC Current Resolution 0.01, 0.1, 1A
Capacitance Accuracy ±(4.0% rdg. +5 dgt.)
Capacitance Range 60, 600.0nF, 6, 60, 600µF, 6, 60mF
Capacitance Resolution 0.01nF, 0.1nF, 0.001μF, 0.01μF, 0.1μF, 0.001mF, 0.01mF
Current Readings AC/DC
Dimensions 10.7" x 3.2" x 1.7" (272 x 81 x 43.5mm)
Resistance Accuracy ±(1% rdg. +2 dgt.) 0.1Ω, 0.001kΩ, 0.01kΩ, 0.1kΩ, 0.001MΩ, 0.01MΩ
Resistance Range 600Ω, 6, 60, 600kΩ, 6, 60MΩ
Voltage Readings AC/DC
Packaged cube cu ft 0.5
Packaged height ft 0.5
Packaged length ft 1
Packaged weight lbs 1.75
Packaged width ft 1
Shipping time Ships in 7-10 days

Order Processing Orders are processed within 2 business days. Orders placed before 2:00 PM PST typically ship within 2 business days. Orders placed after 2:00 PM PST or on weekends/holidays begin processing the next business day.

Local Pickup — FREE Pick up your order at our Delta warehouse at no charge.

Your product is covered by a 12 month Warranty or more if you opted for the extended warranty. Make sure you register your product.
